1.0perating Voltage : 100V AC Max.

2.Current Rating :0.5A Max

3.Contact Resistance :30 mΩ Max.

4.Insulation Resistance :500 MΩ Min.

5.Dielctric Withstand Voltage : 500V AC RMS

6. 0perating Termperature :-40℃ To +105℃

7.Accommodated FFC/FPC Thickness :0.25-0.35mm
