1.Operating Voltage :50V AC Max.

2.Current Rating :0.5A Max.

3.Contact Resistance :20 mΩ Max.

4.Insulation Resistance :100 MΩ Min.

5.Dielctric Withstand Voltage :250V AC RMS.

6.Operating Termperature :40℃ To +105℃

7.Accommodated FFC/FPC Thickness :0.8-1.6mm.
